Lifud driver | Constant Current | Linear Dimmable | 0-10V | US | 11-23W | 100-277V | 25-42V
In de bijlage vindt u uitgebreide informatie over deze driver van Lifud.
LED Flatlight: If you compare our LED Products to traditional lighting you will see that our lighting radiates less heat and has a much longer life span and a very low maintenance cost. Our products are made of quality parts and have a high energy saving level. We think quality is very important so we always make sure our products are tested and have the right certificates.
| Type |
Linear Dim. US 0-10V |
| Model |
LF-GLD025YS |
| Max Output |
11-23W |
| Dim. Functions |
1-10V/PWM/Rx Dim. |
| Input Voltage |
100- 277V |
| Output Voltage |
25V-42V |
| Output Current |
250 / 300 / 350 / 400 / 450 / 500 / 550 mA |
| Efficiency (Typical) |
85% (120 Vac) |
| |
84% (277 Vac) |
| PF (Typical) |
0,95 (120 Vac) |
| |
0,80 (277 Vac) |
| Working Temp. |
-30℃~+50℃ |
| Dimensions |
245*30*21 mm |
| Certificates |
UL, FCC |
| Warranty |
5 Years |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
